10 Tons / Day High Efficient Tube Ice Maker For Aquatic Product Preservation

Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Delivery Time: 30-45 working days
Contact Now

Detail Information

Compressor: Bitzer/Copeland Refrigeration Parts: Danfoss
Electrical Parts: Schneider/LS Refrigerants: R404A/R407C
Cooling Type: Water Condenser Capacity: 10 Tons / 24 Hrs
Application: Aquatic Preservation

Product Description

10 Tons / Day High Efficient Tube Ice Maker For Aquatic Product Preservation







Tube Ice Machine Biref Description
ALLCOLD engineers designed the unique Tube Ice Machine specifically to freeze ice automatically in vertical tubes, momentarily thaw ice loose from the tubes and then cut it into short cylinders with a hole in the center. The hole in the ice cube is formed during the formation of the ice as a result of the falling film of water freezing inside the vertical tubes.

Tube Ice diameter options:
Our tube ice is hollow,cylindrical ice with external diameter of φ22,φ29,φ32 or φ35mm and length of 25-55mm.The diameter of the inner tube ice hole is usually φ5-10mm,but can be adjusted according to the ice making time.

ALLCOLD Tube Ice Machine Features
1. Superb Stability and reliability,long use life
Advanced workmanship and new technology makes high quality tube ice machine, you can always turst on. Rugged, heavy-duty design offers years of trouble-free operation.
2. Energy-efficient and cost saving
The elaborately designed and equipped ice tubers offers a smooth operation,with high efficiency to fulfill the energy-saving
3. Unique Vivid H-M Interactive control system
Give use access to the automatic electrical system which performs sequences for freezing and thawing precisely and dependably then makes great convenience to the customer to operate the machine and settle the trouble
(1). Delicate welding technics with X-RAY./Never leak.
(2). SS 304(Stainless steel) Ice making drum.(generator)
(3). All the material meet the HACCP request.
(4). With the unique water distribution pan and air mouth,pure water evenly flows to the tube wall of the evaporator spirally, which improves the efficiency of heat transfer.

(5). As soon as ice off, the water of low temp. is using for ice-making,which saving energy & increasing the drum volume of production of ice.
(6). Air pressure control excludes the risk of rupture of the evaporator drum.
(7). All the running status playing live in touch-screen, convenient as your family air-conditioning.



Tube Ice Machine Applications
1. Human consumption ice plant

2. Port ice plant
3. Coffee shop,bar,and hotel,etc
4. Supermarket,convenienience shop and restaurant,etc
5. Aquatic products and food fresh preservation
6. Logistic fresh preservation
7. Cgemical and concrete projects

Tube Ice Machine Model & Specifications

ALLCOLD Tube Ice Machine Models & Specifications
Model NO.

Prodction Capacity

KG/24hrs

Ice Teperature

ºC

Total Power

KW

Machine Size

mm

ATM-1T 1,000 -8 8 1,400 × 1,200 × 1,800
ATM-2T 2,000 -8 12 1,600 × 1,200 × 2,000
ATM-3T 3,000 -8 15.5 1,700 × 1,450 × 2,000
ATM-5T 5,000 -8 23.5 1,700 × 1,700 × 2,200
ATM-8T 8,000 -8 30 2,000 × 1,750 × 2,200
ATM-10T 10,000 -8 45 2,900 × 2,280 × 2,600
ATM-15T 15,000 -8 60 3,250 × 3,000 × 4,200
ATM-20T 20,000 -8 85 3,500 × 3,350 × 4,200
ATM-25T 25,000 -8 95 3,850 × 3,650 × 4,200
ATM-30T 30,000 -8 110 4,250 × 3,650 × 4,200
ATM-40T 40,000 -8 150 5,100 × 4,700 × 4,200
ATM-50T 50,000 -8 180 6,000 × 6,000 × 4,500

ALLCOLD will design and offer the most suitable tube ice machine according to the clients' requirements.
Please contact us to get more technical information & quotations.
