Industrial 1 Pallet Pre Cooling Machine Vacuum Chiller 200V 60HZ 3P

Industrial 1 Pallet Pre Cooling Machine Vacuum Chiller 200V 60HZ 3P

MOQ: 1 set
Delivery Period: 30-45 working days
Detail Information
Compressor:
Copeland/Maneurop
Vacuum Pump:
Leybold/Busch/Becker
Refrigeration Parts:
Danfoss/Frascold
Electrical Parts:
Schneider/LS
Refrigerants:
R404A/R407C
Voltage:
200V/60HZ/3P
Vacuum Chamber:
L1.4*W1.2*H2.4m
Application:
Vacuum Cooler For Produce
Capacity:
500KG/1 Pallet
Minimum Order Quantity:
1 set
Delivery Time:
30-45 working days
High Light:

1 Pallet Pre Cooling Machine

,

200V Pre Cooling Machine

,

Refrigeration Parts Vacuum Chiller

Product Description

Industrial 1 Pallet Pre Cooling Machine , Vacuum Chiller 200V 60HZ 3P



Vacuum Cooler Brief Description

Vacuum cooling machine is based on the rapid evaporation of water from produce under low-pressure situations. During the process energy in the form of heat is required to change water from a liquid to a vapor; So vacuum cooling machine can fast cooling down the temperature of produce within 30 minutes.

Because of simple principle and fast cooling speed, vacuum cooling machine is widely used in preservation, transportation and storage of the agricultural products.



Vacuum Cooler Main Components

a. Vacuum chamber--To load your vegetables. The size of the chamber is defined by the amount of pallets you want to cool at the same time, and their individual dimensions. The size of the chamber will decide the number of vacuum pumps to be used.

b. Vacuum system--To takes away the air in vacuum chamber, then cool the vegetables down. For the vacuum we are using pumps of the market leaders Busch and Elmo Rietchle. These pumps hardly need maintenance, are reliable and make very little noise.

c. Refrigeration system--To catch the water vapor in ths chamber so as to ensure the continous cooling process.

The evaporator (water catcher) inside the vacuum chamber condenses the water vapour, and ensures only dry air leaves the vacuum chamber towards the pumps.
Outside the chamber, the cold medium (R 404a) is cooled down by a refrigeration system. The compressor needed for this heat exchange process is supplied by (Germany) or by Hanbell (Taiwan).

d. Control system---To control and show the working condition of the vacuum cooler.





Broccoli Vacuum Cooler Features

1. Green Cooling: Energy saving &Optimal cooling efficiency

2. Radily Cooling: From 30°C to 3°C in 20-30 Minutes

3. Extend Shelf Life: Stay freshness and Nutrition Longer

4. Accurated Control: PLC combine with sensitive sensors&valves

5. Easy Operation Design: Automatic Control work with touch screen

6. Reliable Parts: Busch/Leybold/Elmo Rietschle//Danfoss/Johnson/Schneider/LS



Broccoli Vacuum Cooler Advantages

1. Minimized production losses

2. Improved economic of harvest operations

3. Minimized losses during marketing

4. Improved utilization by consumer

5. Expanded market opportunities





Vacuum Cooler Application Field

1. Vegetables(All Leafy Vegetables/Broccoli/Cauli Flower/Mushrooms/Sweet corn/ etc.)
2. Flowers(Fresh cut flowers)
3. Fruits(Berries/Cherries etc.)





Vacuum Cooler Models&Specifications

Vegetables/Flowers/Fruits Vacuum Cooler Models& Specifications
Model No. Processing Capacity Inside Chamber
mm
Produce Weight
kg
Electricity Type Total Power
kW
AVC-500 1 Pallet 1,400x1,400x2,200 300-500 220V-660V/3P 31
AVC-1000 2 Pallets 2,600x1,400x2,200 800-1,000 220V-660V/3P 39
AVC-1500 3 Pallets 3,900x1,400x2,200 1,200-1,500 220V-660V/3P 47
AVC-2000 4 Pallets 5,200x1,400x2,200 1,500-2,000 220V-660V/3P 72
AVC-3000 6 Pallets 6,500x1,400x2,200 2,300-3,000 220V-660V/3P 98
AVC-4000 8 Pallets 5,300x2,600x2,200 3,200-4,000 220V-660V/3P 121
AVC-5000 10 Pallets 6,600x2,600x2,200 4,200-5,000 220V-660V/3P 145
AVC-6000 12 Pallets 7,900x2,600x2,200 5,200-6,000 220V-660V/3P

166





Customized Options of Our Vacuum Cooler

1. Condensor Options: Air cooling/Water cooling /Evaporative

2. Function Options: Hydro system&Water spray system

3. Door Options: Manual Door/Horizontal Sliding Door/ Upwards Lifting Door/ Vertical Lifting Door
